657A -47

Philips; Eindhoven (tubes international!); Miniwatt

Data
Forum
Pictures
Collections

  • Year
  • 1941/1942
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 228356

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Superheterodyne (common)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and 2 x Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: 657A -47 - Philips; Eindhoven tubes
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 400 x 263 x 183 mm / 15.7 x 10.4 x 7.2 inch
  • Notes

  • Philips 657A -47 is an export model for Denmark, Norway and other Scandinavian countries.

    SW 1: 48...175 m
    SW 2: 13.7...51 m

    See also base model 657A.

  • Price in first year of sale
  • 3,150.00 FIM
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by Timo Rantasaari. See "Data change" for further contributors.
