Credo 750A

Credo 750A; Philips Radios - (ID = 377384) Radio

Credo 750A; Philips Radios - (ID = 377426) Radio

Credo 750A; Philips Radios - (ID = 377385) Radio

Credo 750A; Philips Radios - (ID = 377386) Radio

Credo 750A; Philips Radios - (ID = 377387) Radio

Credo 750A; Philips Radios - (ID = 377388) Radio

Credo 750A; Philips Radios - (ID = 377389) Radio

Credo 750A; Philips Radios - (ID = 377390) Radio

Credo 750A; Philips Radios - (ID = 377391) Radio

Credo 750A; Philips Radios - (ID = 377392) Radio
Credo 750A; Philips Radios - (ID = 627319) Radio Credo 750A; Philips Radios - (ID = 627321) Radio
Credo 750A; Philips Radios - (ID = 815265) Radio Credo 750A; Philips Radios - (ID = 1426745) Radio
Credo 750A; Philips Radios - (ID = 1426752) Radio Credo 750A; Philips Radios - (ID = 1426753) Radio
Credo 750A; Philips Radios - (ID = 1426754) Radio Credo 750A; Philips Radios - (ID = 1426756) Radio
Credo 750A; Philips Radios - (ID = 1426757) Radio
Use red slider bar for more.
Credo 750A; Philips Radios - (ID = 627319) Radio
Philips Radios -: Credo 750A [Radio] ID = 627319 770x612
Select picture or schematic to display from thumbnails on the right and click for download.
For model Credo 750A, Philips Radios - Deutschland

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1937/1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: AK2 AF3 ABC1 ABL1 AM1 AZ1
Main principle Superheterodyne (common); ZF/IF 128 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: Credo 750A - Philips Radios - Deutschland
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes Monoknopf; Klapp-Skala
Net weight (2.2 lb = 1 kg) 14.5 kg / 31 lb 15 oz (31.938 lb)
Price in first year of sale 2'400.00 CZK
Source of data Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Röhren in FS-Bestückungstabellen


All listed radios etc. from Philips Radios - Deutschland
Here you find 2510 models, 2237 with images and 1531 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
