811 22RH811/62Z

811 22RH811/62Z; Philips Finland - (ID = 2126798) Radio
811 22RH811/62Z; Philips Finland - (ID = 2126019) Radio 811 22RH811/62Z; Philips Finland - (ID = 2126020) Radio
811 22RH811/62Z; Philips Finland - (ID = 2126021) Radio 811 22RH811/62Z; Philips Finland - (ID = 2126022) Radio
811 22RH811/62Z; Philips Finland - (ID = 2126023) Radio 811 22RH811/62Z; Philips Finland - (ID = 2126024) Radio
811 22RH811/62Z; Philips Finland - (ID = 2126025) Radio 811 22RH811/62Z; Philips Finland - (ID = 2126027) Radio
811 22RH811/62Z; Philips Finland - (ID = 2126030) Radio 811 22RH811/62Z; Philips Finland - (ID = 2126031) Radio
Use red slider bar for more.
811 22RH811/62Z; Philips Finland - (ID = 2126019) Radio
Philips Finland -: 811 22RH811/62Z [Radio] ID = 2126019 1400x368
Select picture or schematic to display from thumbnails on the right and click for download.
For model 811 22RH811/62Z, Philips Finland - see also Fenno and TeRate

Country:  Finland
Manufacturer / Brand:  Philips Finland - see also Fenno and TeRate
Year: 1971 Category: Broadcast Receiver - or past WW2 Tuner
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: 811 22RH811/62Z - Philips Finland - see also
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 530 x 110 x 210 mm / 20.9 x 4.3 x 8.3 inch
Notes

This model has been made in Finland for the German language market. This version is documented with schematic on the Austrian model page 22RH811.

Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
