• Year
  • 1965 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 100310

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: AG-1025 - Philips Ibérica, COPRESA,
  • Shape
  • Chassis only or for «building in»
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model is part of the collections of the following members.

 Forum

Forum contributions about this model: Philips Ibérica,: AG-1025

Threads: 1 | Posts: 3

Please could somebody advise the correct location for the disconnected end of  this spring on the Grundig/Philips 1025 deck?

Many thanks,

Bryan



Attachments

Bryan McAlley, 28.Jul.21
