For model AG9018 /00 /16, Philips; Eindhoven (tubes international!); Miniwatt:
aus ebay, mit Erlaubnis des Verkäufers em85

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1965/1966 Category: Audio Amplifier or -mixer
Valves / Tubes 11: EF86 EF86 ECC83 ECC83 ECC83 ECC83 EL86 EL86 EL86 EL86 GZ34
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 90; 110; 127; 145; 165; 190; 220; 245 Volt
Loudspeaker - This model requires external speaker(s).
Power out 30 W (unknown quality)
from Radiomuseum.org Model: AG9018 /00 /16 - Philips; Eindhoven tubes
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 434 x 192 x 300 mm / 17.1 x 7.6 x 11.8 inch
Notes Ausgänge 2x 15 Watt an 800 OHM eisenlos, 2x 12 Watt an 8 oder 16 Ohm über eingebaute Ausgangsübertrager, Höhen-, Tiefen-, Balance-, Volumen-Regler, Stereo/Mono-Umschalter, schaltbare Eingäge P.U. (Magnettonabnehmer oder andere - auf der Rückseite umschaltbar), Tuner, Tape.
Net weight (2.2 lb = 1 kg) 13.5 kg / 29 lb 11.8 oz (29.736 lb)
Price in first year of sale 3'980.00 ATS
Source of data Handbuch VDRG 1965/1966
Mentioned in Österreichische Radioschau (ÖRS) (Heft 4, 1965, Seite 202)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Stefan Weigelt. See "Data change" for further contributors.
