AM/FM Stereophonic Radiogram F6G40AT (640AT)

AM/FM Stereophonic Radiogram F6G40AT ; Philips Electrical, (ID = 2316827) Radio

AM/FM Stereophonic Radiogram F6G40AT ; Philips Electrical, (ID = 2316828) Radio

AM/FM Stereophonic Radiogram F6G40AT ; Philips Electrical, (ID = 2316829) Radio

AM/FM Stereophonic Radiogram F6G40AT ; Philips Electrical, (ID = 2316831) Radio

AM/FM Stereophonic Radiogram F6G40AT ; Philips Electrical, (ID = 2316832) Radio

AM/FM Stereophonic Radiogram F6G40AT ; Philips Electrical, (ID = 2316834) Radio
Use red slider bar for more.
AM/FM Stereophonic Radiogram F6G40AT ; Philips Electrical, (ID = 2316827) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Philips Electrical, Lamps, Industrial - Miniwatt; London
Year: 1965 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 15: AF115 AF114 AF115 AF116 AF116 AF116 OC70 OC71 OC71 OC81D or. AC128 OC71 OC71 OC81D or. AC128 AD140 or. AD149 AD140 or. AD149
Main principle Super-Heterodyne (Super in general); ZF/IF 470/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker 2 Loudspeakers
Power out 6 W (unknown quality)
from Radiomuseum.org Model: AM/FM Stereophonic Radiogram F6G40AT - Philips Electrical, Lamps,
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes

A mains powered AM/FM stereophonic radiogram with a 2 x 3 watt transistor amplifier, two loudspeakers, a Philips AG1025 four speed autochanger and an AM/FM transistor tuner covering MW (185-555 metres), LW (1080-1875 metres), SW (17-50 metres) and VHF (87-100 MHz). Metal rectifier. Sockets for external AM and FM aerials, tape recorder and for an optional multiplex FM stereo adaptor.

Similar to the Stella ST328AT stereophonic radiogram which has a Garrard Autoslim autochanger.

Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1726 dated 22 October 1965)

Model page created by Howard Craven. See "Data change" for further contributors.
