Araldo 3 B3I90A

Araldo 3 B3I90A; Philips Italy; (ID = 1902071) Radio

Araldo 3 B3I90A; Philips Italy; (ID = 1902072) Radio

Araldo 3 B3I90A; Philips Italy; (ID = 517129) Radio

Araldo 3 B3I90A; Philips Italy; (ID = 1902073) Radio

Araldo 3 B3I90A; Philips Italy; (ID = 1902074) Radio

Araldo 3 B3I90A; Philips Italy; (ID = 1902075) Radio

Araldo 3 B3I90A; Philips Italy; (ID = 1902076) Radio
Araldo 3 B3I90A; Philips Italy; (ID = 339323) Radio Araldo 3 B3I90A; Philips Italy; (ID = 655485) Radio
Araldo 3 B3I90A; Philips Italy; (ID = 655483) Radio Araldo 3 B3I90A; Philips Italy; (ID = 246674) Radio
Araldo 3 B3I90A; Philips Italy; (ID = 655482) Radio Araldo 3 B3I90A; Philips Italy; (ID = 655484) Radio
Araldo 3 B3I90A; Philips Italy; (ID = 1158166) Radio Araldo 3 B3I90A; Philips Italy; (ID = 1268688) Radio
Araldo 3 B3I90A; Philips Italy; (ID = 1530737) Radio Araldo 3 B3I90A; Philips Italy; (ID = 1530738) Radio
Use red slider bar for more.
Araldo 3 B3I90A; Philips Italy; (ID = 339323) Radio
Philips Italy;: Araldo 3 B3I90A [Radio] ID = 339323 382x236
Select picture or schematic to display from thumbnails on the right and click for download.
For model Araldo 3 B3I90A, Philips Italy; Milano (MI):
Foto per cortesia del venditore ebay: orsomaria62 (#230148050096)

Country:  Italy
Manufacturer / Brand:  Philips Italy; Milano (MI)
Year: 1959–1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: UCC85 UCH81 UF89 UABC80 DM71 UL84 UY85
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Araldo 3 B3I90A - Philips Italy; Milano MI
Material Moulded (Bakelite or Plastics)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 330 x 190 x 180 mm / 13 x 7.5 x 7.1 inch
Notes Mobile in diverse varianti di colore. Dimensioni altoparlante: 15,5 x 10,3 cm. Sintonia a permeabilità variabile.

Autotrafo, keine Netztrennung !!!

Net weight (2.2 lb = 1 kg) 3.7 kg / 8 lb 2.4 oz (8.15 lb)
Price in first year of sale 35'000.00 ITL
Source of data Guida Pratica Antique Radio (1) 1999
Mentioned in Guida Pratica Antique Radio III (2000)
Literature/Schematics (1) -- Original-techn. papers. (Servizio Philips per laboratori)

Model page created by Rino Ferro † 2008. See "Data change" for further contributors.
