Automatic Cassette Recorder N2213 /15

Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2248017) R-Player

Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2250727) R-Player

Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2250728) R-Player

Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2250729) R-Player

Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2250730) R-Player

Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2250731) R-Player

Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2250732) R-Player

Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2250733) R-Player

Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2250734) R-Player

Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2250735) R-Player
Use red slider bar for more.
Automatic Cassette Recorder N2213 /15; Philips - Österreich (ID = 2248017) R-Player
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1976 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 5: BC549 BC548 BC548 BC548 BC548 TCA760 TCA900 BAW62 BAX12 BAX12
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220-240 / C: 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out 0.8 W (unknown quality)
from Radiomuseum.org Model: Automatic Cassette Recorder N2213 /15 - Philips - Österreich
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 190 x 65 x 265 mm / 7.5 x 2.6 x 10.4 inch
Notes

Netzspannung am Transformator auf 110V umlötbar, siehe Schaltplan.



Net weight (2.2 lb = 1 kg) 1.4 kg / 3 lb 1.3 oz (3.084 lb)
Mentioned in -- Original-techn. papers.

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
