B2AL17U; Philips Argentina, (ID = 1044237) Radio
Philips Argentina,: B2AL17U [Radio] ID = 1044237 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model B2AL17U, Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires

Country:  Argentina
Manufacturer / Brand:  Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires
Year: 1955 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UBC41 UL41 UY41
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2 W (unknown quality)
from Radiomuseum.org Model: B2AL17U - Philips Argentina, FAPESA,
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 290 x 180 x 170 mm / 11.4 x 7.1 x 6.7 inch
Notes Built-in ferrite rod antenna (Ferroceptor).
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Source of data -- Original-techn. papers.

Model page created by Bernardo Henze. See "Data change" for further contributors.



All listed radios etc. from Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires
Here you find 199 models, 136 with images and 138 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
