For model B2CA67U, Philips; Calcutta:
pic taken from serv doc, no other source available please consider as front picture as done for model B2CA99U
Country:  India
Manufacturer / Brand:  Philips; Calcutta
Year: 1957/1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UBC41 UL41 UY42
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Power type and voltage AC/DC-set / 110-127 or 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Model: B2CA67U - Philips; Calcutta
Material Moulded (Bakelite or Plastics)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).

Speaker type 40 239 58 (Z = 5 ohms).

Wave bands:
MW: 185 - 580 m
SW: 16.75 - 63.2 m

Power consumption 40 W.

For operation on 110 - 127 AC/DC mains, a wire needs to be interrupted on the chassis.

This radio shares documentation (and chassis) with model B2CA66U.

Mentioned in -- Original-techn. papers.

Model page created by Robert Kooijman. See "Data change" for further contributors.
