B3AL18U

B3AL18U; Philips Argentina, (ID = 2338873) Radio B3AL18U; Philips Argentina, (ID = 1249900) Radio
B3AL18U; Philips Argentina, (ID = 1249897) Radio B3AL18U; Philips Argentina, (ID = 1249895) Radio
B3AL18U; Philips Argentina, (ID = 1249899) Radio B3AL18U; Philips Argentina, (ID = 1249903) Radio
B3AL18U; Philips Argentina, (ID = 1249904) Radio B3AL18U; Philips Argentina, (ID = 1249905) Radio
Use red slider bar for more.
B3AL18U; Philips Argentina, (ID = 2338873) Radio
Philips Argentina,: B3AL18U [Radio] ID = 2338873 1400x900
Select picture or schematic to display from thumbnails on the right and click for download.
For model B3AL18U, Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires

Country:  Argentina
Manufacturer / Brand:  Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires
Year: 1955 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UBC41 UL41 UY41
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz; 2 AF stage(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 2 W (unknown quality)
from Radiomuseum.org Model: B3AL18U - Philips Argentina, FAPESA,
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 306 x 240 x 170 mm / 12 x 9.4 x 6.7 inch
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Source of data - - Manufacturers Literature

Model page created by Hector Ruben Menendez. See "Data change" for further contributors.
