B3AL57-T

B3AL57-T; Philips Argentina, (ID = 713686) Radio
B3AL57-T; Philips Argentina, (ID = 713685) Radio B3AL57-T; Philips Argentina, (ID = 2382684) Radio
B3AL57-T; Philips Argentina, (ID = 2382685) Radio B3AL57-T; Philips Argentina, (ID = 2382686) Radio
B3AL57-T; Philips Argentina, (ID = 2382687) Radio
Use red slider bar for more.
B3AL57-T; Philips Argentina, (ID = 713685) Radio
Philips Argentina,: B3AL57-T [Radio] ID = 713685 480x280
Select picture or schematic to display from thumbnails on the right and click for download.
For model B3AL57-T, Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires:
imagen del Manual de Servicio Philips 1966

Country:  Argentina
Manufacturer / Brand:  Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires
Year: 1964 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: AF115 AF117 AF117 OC71 OC71 OC74 OC74 OA79 OA79
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz; 3 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: B3AL57-T - Philips Argentina, FAPESA,
Material Moulded (Bakelite or Plastics)
Shape Tablemodel, low profile (big size).
Notes Philips Argentina B3AL57-T;
Rango de Frecuencias OM 530 a 1610 kHz, OC 5,8 a 9,8 MHz.
Consumo 20 mA a 50 mW y 200 mA a 500 mW de potencia de salida.
Es identico al modelo B3AL56-T, excepto el rango de frecuencias en OC.
Las perillas de sintonia y volumen son las mismas que las de los modelos B2AL47-T, B2AL56-T, B2AL46-U, y la perilla de volumen es igual a la del modelo B0AL46-U.
Literature/Schematics (1) -- Schematic (Manual de Servicio Philips 1966)

Model page created by Jose Vigil. See "Data change" for further contributors.
