Juliette B4S51A /02

Juliette B4S51A /02; Philips, Svenska AB, (ID = 44154) Radio Juliette B4S51A /02; Philips, Svenska AB, (ID = 44155) Radio
Juliette B4S51A /02; Philips, Svenska AB, (ID = 53860) Radio Juliette B4S51A /02; Philips, Svenska AB, (ID = 2380010) Radio
Juliette B4S51A /02; Philips, Svenska AB, (ID = 2380011) Radio Juliette B4S51A /02; Philips, Svenska AB, (ID = 2380012) Radio
Juliette B4S51A /02; Philips, Svenska AB, (ID = 2380013) Radio Juliette B4S51A /02; Philips, Svenska AB, (ID = 2380014) Radio
Use red slider bar for more.
Juliette B4S51A /02; Philips, Svenska AB, (ID = 44154) Radio
Philips, Svenska AB,: Juliette B4S51A /02 [Radio] ID = 44154 930x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Juliette B4S51A /02, Philips, Svenska AB, Stockholm:
This is a radio from the mid-60\'s, with the \'Magic Eye\'. It has a very nice sound. The FM selector knob is typical Philips. It has \'station pre-selection\' indicators, small plastic flaps, which you move to the wished position, and the tuning knob \'clicks\' into them, to simplify the search for the favorite station.

Country:  Sweden
Manufacturer / Brand:  Philips, Svenska AB, Stockholm
Year: 1966 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EBC81 EM84 EL86
Semiconductors (the count is only for transistors) OA79 OA79 BA102 B250C100
Main principle Super-Heterodyne (Super in general); ZF/IF 468/10850 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 inch = 16.5 cm
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Juliette B4S51A /02 - Philips, Svenska AB, Stockholm
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 548 x 190 x 166 mm / 21.6 x 7.5 x 6.5 inch
Notes

Connector for external loudspeaker (5 Ohms).

See also model B4S51A /00 /13 (differences unknown). Some models have a sticker "/02" on the back cover, presumably replacing the original "/00" or "/13".

Collectors' prices

Model page created by Jörgen Svensson. See "Data change" for further contributors.



All listed radios etc. from Philips, Svenska AB, Stockholm
Here you find 189 models, 175 with images and 67 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
