B4SF92A

B4SF92A; Philips Finland - (ID = 1649231) Radio B4SF92A; Philips Finland - (ID = 1649233) Radio
B4SF92A; Philips Finland - (ID = 1649234) Radio B4SF92A; Philips Finland - (ID = 1952537) Radio
B4SF92A; Philips Finland - (ID = 1952538) Radio B4SF92A; Philips Finland - (ID = 1952539) Radio
B4SF92A; Philips Finland - (ID = 1952540) Radio B4SF92A; Philips Finland - (ID = 1952541) Radio
B4SF92A; Philips Finland - (ID = 1952542) Radio B4SF92A; Philips Finland - (ID = 1952543) Radio
Use red slider bar for more.
B4SF92A; Philips Finland - (ID = 1649231) Radio
Philips Finland -: B4SF92A [Radio] ID = 1649231 933x356
Select picture or schematic to display from thumbnails on the right and click for download.
For model B4SF92A, Philips Finland - see also Fenno and TeRate

Country:  Finland
Manufacturer / Brand:  Philips Finland - see also Fenno and TeRate
Year: 1959 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EBF89 ECL82 EM80 ECL82
Semiconductors (the count is only for transistors) OA79 OA79 OA79 B155C120
Main principle Superheterodyne (common); ZF/IF 468/10850 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: B4SF92A - Philips Finland - see also
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 640 x 230 x 230 mm / 25.2 x 9.1 x 9.1 inch
Notes

Speaker type AD3700AM (Z = 800 ohms).

See also similar model Conserton Puck V529.

Net weight (2.2 lb = 1 kg) 7.1 kg / 15 lb 10.2 oz (15.639 lb)

Model page created by Timo Rantasaari. See "Data change" for further contributors.



All listed radios etc. from Philips Finland - see also Fenno and TeRate
Here you find 158 models, 148 with images and 38 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
