B4X76A; Philips; Eindhoven (ID = 1331799) Radio
Philips; Eindhoven: B4X76A [Radio] ID = 1331799 767x542
Select picture or schematic to display from thumbnails on the right and click for download.
For model B4X76A, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH81 EF89 EBC81 EL95 EM80 EZ80
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 90-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: B4X76A - Philips; Eindhoven tubes
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 365 x 262 x 201 mm / 14.4 x 10.3 x 7.9 inch
Mentioned in - - Manufacturers Literature

Model page created by Mario Coelho. See "Data change" for further contributors.
