Babette 22RL382

Babette 22RL382; Philips - Österreich (ID = 119270) Radio

Babette 22RL382; Philips - Österreich (ID = 119271) Radio

Babette 22RL382; Philips - Österreich (ID = 390967) Radio

Babette 22RL382; Philips - Österreich (ID = 581258) Radio

Babette 22RL382; Philips - Österreich (ID = 581260) Radio

Babette 22RL382; Philips - Österreich (ID = 581261) Radio

Babette 22RL382; Philips - Österreich (ID = 581255) Radio

Babette 22RL382; Philips - Österreich (ID = 581256) Radio

Babette 22RL382; Philips - Österreich (ID = 390968) Radio

Babette 22RL382; Philips - Österreich (ID = 390966) Radio
Babette 22RL382; Philips - Österreich (ID = 111899) Radio
Use red slider bar for more.
Babette 22RL382; Philips - Österreich (ID = 111899) Radio
Philips - Österreich: Babette 22RL382 [Radio] ID = 111899 865x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Babette 22RL382, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF124 AF125 AF125 AF125 AF125 AC127 AC132 AC127 AC132 AA119 AA119 AA119 BA114
Main principle Super-Heterodyne (Super in general); ZF/IF 460 kHz; 3 AF stage(s)
Tuned circuits 5 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 x 1.5 & 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Babette 22RL382 - Philips - Österreich
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 279 x 135 x 56 mm / 11 x 5.3 x 2.2 inch
Notes 2 Ausführungen: schwarz und beige
Parallelgerät zum Horny SA7310
In Deutschland auch als Don 22RL382.
Collectors' prices
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
