BCH421A

BCH421A; Philips - Schweiz (ID = 1688786) Radio

BCH421A; Philips - Schweiz (ID = 1688789) Radio

BCH421A; Philips - Schweiz (ID = 1688790) Radio

BCH421A; Philips - Schweiz (ID = 1688792) Radio

BCH421A; Philips - Schweiz (ID = 1688787) Radio

BCH421A; Philips - Schweiz (ID = 1688791) Radio

BCH421A; Philips - Schweiz (ID = 1688796) Radio

BCH421A; Philips - Schweiz (ID = 1688799) Radio
BCH421A; Philips - Schweiz (ID = 745816) Radio BCH421A; Philips - Schweiz (ID = 573964) Radio
BCH421A; Philips - Schweiz (ID = 573973) Radio BCH421A; Philips - Schweiz (ID = 573968) Radio
BCH421A; Philips - Schweiz (ID = 573970) Radio BCH421A; Philips - Schweiz (ID = 1687394) Radio
BCH421A; Philips - Schweiz (ID = 1687396) Radio BCH421A; Philips - Schweiz (ID = 1687397) Radio
BCH421A; Philips - Schweiz (ID = 1687400) Radio BCH421A; Philips - Schweiz (ID = 1687401) Radio
Use red slider bar for more.
BCH421A; Philips - Schweiz (ID = 745816) Radio
Philips - Schweiz: BCH421A [Radio] ID = 745816 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model BCH421A, Philips - Schweiz

Country:  Switzerland
Manufacturer / Brand:  Philips - Schweiz
Year: 1952/1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EBC41 EL41 EM34 AZ41
Main principle Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: BCH421A - Philips - Schweiz
Material Wooden case
Dimensions (WHD) 470 x 320 x 205 mm / 18.5 x 12.6 x 8.1 inch
Notes

Zweite Kurzwelle: Gedehntes Kurzwellenband auf 50 m (6 MHz)



Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)
Price in first year of sale 495.00 SFr
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
