BCH424A-10; Philips - Schweiz (ID = 360788) Radio
Philips - Schweiz: BCH424A-10 [Radio] ID = 360788 933x622
Select picture or schematic to display from thumbnails on the right and click for download.
For model BCH424A-10, Philips - Schweiz

Country:  Switzerland
Manufacturer / Brand:  Philips - Schweiz
Year: 1954 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH81 EBF80 EBC41 EL84 AZ41
Main principle Superheterodyne (common); ZF/IF 470 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
Power out
from Radiomuseum.org Model: BCH424A-10 - Philips - Schweiz
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 470 x 330 x 230 mm / 18.5 x 13 x 9.1 inch
Net weight (2.2 lb = 1 kg) 8 kg / 17 lb 9.9 oz (17.621 lb)
Source of data - - Data from my own collection

Model page created by Christian Schaufelberger. See "Data change" for further contributors.



All listed radios etc. from Philips - Schweiz
Here you find 287 models, 210 with images and 213 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
