For model BCH453A, Philips - Schweiz

Country:  Switzerland
Manufacturer / Brand:  Philips - Schweiz
Year: 1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EBF80 EF85 EABC80 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz; 2 AF stage(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 14 cm = 5.5 inch
Power out
from Radiomuseum.org Model: BCH453A - Philips - Schweiz
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 520 x 350 x 210 mm / 20.5 x 13.8 x 8.3 inch
Notes Hergestellt bei Philips-Schweiz, La Chaux de Fonds.
Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Price in first year of sale 350.00 sFr
Mentioned in -- Original prospect or advert

Model page created by Stefan Kälin. See "Data change" for further contributors.
