• Year
  • 1949
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 147465

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • AC/DC-set / 110-240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: 370U - Philips Radio A/S; København
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 395 x 240 x 165 mm / 15.6 x 9.4 x 6.5 inch
  • Notes
  • The Danish BDK370U is similar to model BX370U from Philips Netherlands.
  • Net weight (2.2 lb = 1 kg)
  • 5 kg / 11 lb 0.2 oz (11.013 lb)
  • Source of data
  • - - Data from my own collection
  • Author
  • Model page created by Peter Hughes. See "Data change" for further contributors.
