Symfoni 682U

Symfoni 682U; Philips Radio A/S; K (ID = 499546) Radio Symfoni 682U; Philips Radio A/S; K (ID = 499548) Radio
Symfoni 682U; Philips Radio A/S; K (ID = 499261) Radio Symfoni 682U; Philips Radio A/S; K (ID = 499263) Radio
Symfoni 682U; Philips Radio A/S; K (ID = 499551) Radio Symfoni 682U; Philips Radio A/S; K (ID = 1047085) Radio
Symfoni 682U; Philips Radio A/S; K (ID = 1047086) Radio Symfoni 682U; Philips Radio A/S; K (ID = 1047087) Radio
Symfoni 682U; Philips Radio A/S; K (ID = 1047089) Radio
Use red slider bar for more.
Symfoni 682U; Philips Radio A/S; K (ID = 499546) Radio
Philips Radio A/S; K: Symfoni 682U [Radio] ID = 499546 800x641
Select picture or schematic to display from thumbnails on the right and click for download.
For model Symfoni 682U, Philips Radio A/S; København

Country:  Denmark
Manufacturer / Brand:  Philips Radio A/S; København
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: UCH4 UCH4 UCH4 UBL1 UM4 UBL1 UY1N UY1N
Main principle Superheterodyne (common); ZF/IF 441 kHz
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Symfoni 682U - Philips Radio A/S; København
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 590 x 380 x 270 mm / 23.2 x 15 x 10.6 inch
Notes The Philips Denmark (DK) model BDK682U has 3 short wave bands.
Net weight (2.2 lb = 1 kg) 12.5 kg / 27 lb 8.5 oz (27.533 lb)
Price in first year of sale 395.00 Hfl
Source of data Technisch- Commercieel - Radio Vademecum Staleman

Model page created by John Koster. See "Data change" for further contributors.



All listed radios etc. from Philips Radio A/S; København
Here you find 101 models, 98 with images and 55 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
