BE-541-A

BE-541-A; Philips Ibérica, (ID = 234321) Radio

BE-541-A; Philips Ibérica, (ID = 234323) Radio

BE-541-A; Philips Ibérica, (ID = 234322) Radio
BE-541-A; Philips Ibérica, (ID = 114464) Radio BE-541-A; Philips Ibérica, (ID = 342044) Radio
BE-541-A; Philips Ibérica, (ID = 342045) Radio BE-541-A; Philips Ibérica, (ID = 342046) Radio
BE-541-A; Philips Ibérica, (ID = 349729) Radio BE-541-A; Philips Ibérica, (ID = 1193811) Radio
BE-541-A; Philips Ibérica, (ID = 1193812) Radio BE-541-A; Philips Ibérica, (ID = 1193816) Radio
BE-541-A; Philips Ibérica, (ID = 1877580) Radio BE-541-A; Philips Ibérica, (ID = 1877581) Radio
Use red slider bar for more.
BE-541-A; Philips Ibérica, (ID = 114464) Radio
Philips Ibérica,: BE-541-A [Radio] ID = 114464 481x320
Select picture or schematic to display from thumbnails on the right and click for download.
For model BE-541-A, Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes; Madrid, Barcelona

Country:  Spain
Manufacturer / Brand:  Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes; Madrid, Barcelona
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EF41 ECH81 EBF80 EBC41 DM71 EL84 EZ80
Main principle Superhet with RF-stage; ZF/IF 452 kHz; 2 AF stage(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: BE-541-A - Philips Ibérica, COPRESA,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 510 x 340 x 240 mm / 20.1 x 13.4 x 9.4 inch
Notes

Modelo dotado de antenas de cuadro cruzadas.





Net weight (2.2 lb = 1 kg) 7 kg / 15 lb 6.7 oz (15.419 lb)
Price in first year of sale 3'894.00 ESP
External source of data Ernst Erb
Source of data Radio Historia y Técnica, J.J.E.
Literature/Schematics (1) -- Original-techn. papers. (Anuncio ABC 27-12-1955)


All listed radios etc. from Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes; Madrid, Barcelona
Here you find 538 models, 474 with images and 439 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
