BF431A; Philips France; (ID = 1372561) Radio
Philips France;: BF431A [Radio] ID = 1372561 933x698
Select picture or schematic to display from thumbnails on the right and click for download.
For model BF431A, Philips France; Paris:
F_Philips_BF431A

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH42 UF41 UBC41 UL41 DM70 UY41
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out 1.7 W (unknown quality)
from Radiomuseum.org Model: BF431A - Philips France; Paris
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 470 x 320 x 200 mm / 18.5 x 12.6 x 7.9 inch
Notes

4 gammes d'ondes : GO de 1100 à 1950 m, PO de 185 à 572 m, OC de 16.5 à 51 m, BE (bande étalée) de 47 à 50.8 m. Cadre ferrocapteur incorporé orientable PO-GO, plaque antenne OC. Tonalité réglage continu. Prise pick-up.

Malgré le jeu de lampes série U (tous courants) ce modèle ne fonctionne que sur secteur alternatif 50 périodes. Existe aussi en exécution pour 25 périodes.

Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)
Price in first year of sale 31'800.00 FRF
Collectors' prices
Mentioned in -- Original-techn. papers.

Model page created by Karsten Hauger. See "Data change" for further contributors.
