For model BF151A /01 /02, Philips France; Paris

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1955/1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UBC41 UL41 UY41 or UY42
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 117-123; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: BF151A /01 /02 - Philips France; Paris
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 240 x 170 x 130 mm / 9.4 x 6.7 x 5.1 inch
Notes

4 gammes d'ondes : bande étalée (BE) sur 50 m, OC de 16 à 52 m, PO de 185 à 575 m, GO de 1150 à 1950 m. Cadre ferroxcube de 20 cm et antenne plaque pour OC incorporés. HP elliptique de 10 x 14cm.

Coffret polystyrène en deux coquilles, motif décoratif teinte or, grille cadran plexiglass.

2 exécutions :

  • /01 bordeaux
  • /02 ivoire

Équivalent au Radiola RA155A.

La lampe UY41 n'est mentionnée que dans une publicité d'année 1955.

Net weight (2.2 lb = 1 kg) 2.6 kg / 5 lb 11.6 oz (5.727 lb)
Price in first year of sale 16'450.00 FRF
Collectors' prices
Mentioned in -- Original prospect or advert (Dépliant "Série Synchro-Magnétique" 1956)
Literature/Schematics (1) Schémathèque Toute la Radio (STR) (No. 917)
Literature/Schematics (2) -- Original-techn. papers.

Model page created by Patrice Zeissloff. See "Data change" for further contributors.
