BI290U

BI290U; Philips Italy; (ID = 252054) Radio

BI290U; Philips Italy; (ID = 1108496) Radio
BI290U; Philips Italy; (ID = 124973) Radio BI290U; Philips Italy; (ID = 432588) Radio
BI290U; Philips Italy; (ID = 432589) Radio BI290U; Philips Italy; (ID = 988942) Radio
BI290U; Philips Italy; (ID = 988943) Radio BI290U; Philips Italy; (ID = 988944) Radio
BI290U; Philips Italy; (ID = 988945) Radio BI290U; Philips Italy; (ID = 988946) Radio
BI290U; Philips Italy; (ID = 988947) Radio BI290U; Philips Italy; (ID = 988948) Radio
Use red slider bar for more.
BI290U; Philips Italy; (ID = 124973) Radio
Philips Italy;: BI290U [Radio] ID = 124973 851x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model BI290U, Philips Italy; Milano (MI)

Country:  Italy
Manufacturer / Brand:  Philips Italy; Milano (MI)
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH41 UAF41 UAF41 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 468 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 110-125; 145-160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: BI290U - Philips Italy; Milano MI
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 270 x 220 x 190 mm / 10.6 x 8.7 x 7.5 inch
Notes

Il funzionamento a 220 V è ottenuto inserendo una resistenza da 315 Ω in serie all'alimentazione, con il commutatore in posizione 145-160.

Il telaio è sempre collegato alla rete elettrica sia in funzionamento CC che CA. Non tutti i casi sono dichiarati poichè spesso chi propone il modello non lo può sapere.

Literature/Schematics (1) Schemi di apparecchi radio ( Ravalico 1953 ) (pag. 208)

Model page created by Alessandro De Poi. See "Data change" for further contributors.
