BIF 360A

BIF 360A; Philips Electrical (ID = 1287152) Radio

BIF 360A; Philips Electrical (ID = 1287153) Radio

BIF 360A; Philips Electrical (ID = 1287154) Radio

BIF 360A; Philips Electrical (ID = 1287156) Radio

BIF 360A; Philips Electrical (ID = 1287157) Radio

BIF 360A; Philips Electrical (ID = 1287159) Radio

BIF 360A; Philips Electrical (ID = 1287160) Radio

BIF 360A; Philips Electrical (ID = 1287161) Radio

BIF 360A; Philips Electrical (ID = 1287162) Radio

BIF 360A; Philips Electrical (ID = 1287164) Radio
Use red slider bar for more.
BIF 360A; Philips Electrical (ID = 1287152) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Ireland
Manufacturer / Brand:  Philips Electrical (Ireland) Ltd.; Dublin
Year: 1958 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH81 EBF80 EBC41 EL84 DM71 EZ80
Main principle Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: BIF 360A - Philips Electrical Ireland Ltd
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 21.5 x 31 x 15.5 inch / 546 x 787 x 394 mm
Source of data -- Original-techn. papers.

Model page created by Jose Casas-Avalos. See "Data change" for further contributors.



All listed radios etc. from Philips Electrical (Ireland) Ltd.; Dublin
Here you find 25 models, 19 with images and 10 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
