BX200U /12

BX200U /12; Philips Belgium (ID = 2554940) Radio

BX200U /12; Philips Belgium (ID = 2554941) Radio

BX200U /12; Philips Belgium (ID = 2554942) Radio

BX200U /12; Philips Belgium (ID = 2554943) Radio

BX200U /12; Philips Belgium (ID = 2554944) Radio

BX200U /12; Philips Belgium (ID = 2554945) Radio
BX200U /12; Philips Belgium (ID = 2554936) Radio BX200U /12; Philips Belgium (ID = 2554937) Radio
BX200U /12; Philips Belgium (ID = 2554938) Radio BX200U /12; Philips Belgium (ID = 2554939) Radio
Use red slider bar for more.
BX200U /12; Philips Belgium (ID = 2554936) Radio
Philips Belgium: BX200U /12 [Radio] ID = 2554936 1024x768
Select picture or schematic to display from thumbnails on the right and click for download.
For model BX200U /12, Philips Belgium (Belgien):
Picture from auction site 'Marktplaats' (seller: veliko).

Country:  Belgium
Manufacturer / Brand:  Philips Belgium (Belgien)
Year: 1950 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UBC41 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110-127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11 cm = 4.3 inch
Power out
from Radiomuseum.org Model: BX200U /12 - Philips Belgium Belgien
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 240 x 175 x 145 mm / 9.4 x 6.9 x 5.7 inch
Notes

Model BX200U-12 is identical with Philips model BX200U, except for a different cabinet color.

Net weight (2.2 lb = 1 kg) 2.6 kg / 5 lb 11.6 oz (5.727 lb)
Mentioned in -- Original-techn. papers.

Model page created by Gidi Verheijen. See "Data change" for further contributors.



All listed radios etc. from Philips Belgium (Belgien)
Here you find 469 models, 448 with images and 275 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
