For model BX594A, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1949/1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH21 EAF42 EAF42 EBL21 EM34 AZ1
Main principle Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 19 cm = 7.5 inch
Power out 4.5 W (unknown quality)
from Radiomuseum.org Model: BX594A - Philips; Eindhoven tubes
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 500 x 350 x 240 mm / 19.7 x 13.8 x 9.4 inch
Notes

This radio can accomodate EAF41 as well as EAF42: see wiring diagram.

AM radio for external antenna:
  • LW: 150 - 420 kHz.
  • BC: 517 - 1620 kHz.
  • SW1: 5,94 - 9,38 MHz.
  • SW2: 9,38 - 13,95 MHz.
  • SW3: 11,55 - 17,65 MHz.
  • SW4: 15 - 22,2 MHz.
Loudspeaker: 9748-05 (5Ω).
Dial lamp: 2x 8045D (E10, 6.3V/320mA).
Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
Price in first year of sale 360.00 Hfl
Collectors' prices
Source of data Technisch- Commercieel - Radio Vademecum Staleman
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
