Raff V472; Dux Radio AB; (ID = 577520) Radio

Raff V472; Dux Radio AB; (ID = 577521) Radio

Raff V472; Dux Radio AB; (ID = 577522) Radio

Raff V472; Dux Radio AB; (ID = 577523) Radio

Raff V472; Dux Radio AB; (ID = 577524) Radio

Raff V472; Dux Radio AB; (ID = 577525) Radio
Raff V472; Dux Radio AB; (ID = 353373) Radio Raff V472; Dux Radio AB; (ID = 353375) Radio
Raff V472; Dux Radio AB; (ID = 353374) Radio Raff V472; Dux Radio AB; (ID = 198761) Radio
Use red slider bar for more.
Raff V472; Dux Radio AB; (ID = 353373) Radio
Dux Radio AB;: Raff V472 [Radio] ID = 353373 845x454
Select picture or schematic to display from thumbnails on the right and click for download.
For model Raff V472, Dux Radio AB; Stockholm

Country:  Sweden
Manufacturer / Brand:  Dux Radio AB; Stockholm
Year: 1966 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EBC81 EM84 EL86
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Raff V472 - Dux Radio AB; Stockholm
Material Wooden case
Shape Book-shelf unit.
Notes Diodes: 2× OA79, BA102.
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Jörgen Svensson. See "Data change" for further contributors.



All listed radios etc. from Dux Radio AB; Stockholm
Here you find 166 models, 148 with images and 76 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.


Collection of a member from FIN
