HCH511A

HCH511A; Philips - Schweiz (ID = 2407246) Radio

HCH511A; Philips - Schweiz (ID = 2407247) Radio

HCH511A; Philips - Schweiz (ID = 2407248) Radio

HCH511A; Philips - Schweiz (ID = 2407249) Radio

HCH511A; Philips - Schweiz (ID = 2407250) Radio

HCH511A; Philips - Schweiz (ID = 2407251) Radio

HCH511A; Philips - Schweiz (ID = 2407253) Radio

HCH511A; Philips - Schweiz (ID = 2407254) Radio
Use red slider bar for more.
HCH511A; Philips - Schweiz (ID = 2407246) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Switzerland
Manufacturer / Brand:  Philips - Schweiz
Year: 1951/1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EBC41 EL41 EM34 AZ41
Main principle Superheterodyne (common); ZF/IF 452 kHz
Details
Power type and voltage Alternating Current supply (AC) / 110-245 Volt
Loudspeaker Presumably Dynamic Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: HCH511A - Philips - Schweiz
Material Wooden case
Notes ZF kann abweichen
Price in first year of sale 795.00 SFr
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Die Tungsram-Tabellen führen das Modell auf.
