Integrated Stereo Amplifier 305 22AH305 /00 /15

• Country
• Belgium

• Manufacturer / Brand
• Philips Belgium (Belgien)

• Year
• 1981 ?

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 249323

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 42

• Semiconductors
• BC559 BC548 BC558 BC557 BC449 BD140 BC337 BD137 BD138 BD313 BD314 BD677 BA315 BAW62 BZX79 BY225-100

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 60 W (90 W max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: Integrated Stereo Amplifier 305 22AH305 /00 /15 - Philips Belgium Belgien

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 405 x 102 x 287 mm / 15.9 x 4 x 11.3 inch

• Notes

• Separate hybrid or thickfilm phono preamplifier.
  Each transistor or diode type listed once only.

• Net weight (2.2 lb = 1 kg)
• 10 kg / 22 lb 0.4 oz (22.026 lb)
