Kathodenstrahl-Oszillograph GM3155

Philips; Eindhoven (tubes international!); Miniwatt

  • Year
  • 1940 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 181458

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 110-245 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Kathodenstrahl-Oszillograph GM3155 - Philips; Eindhoven tubes
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Dimensions (WHD)
  • 167 x 227 x 251 mm / 6.6 x 8.9 x 9.9 inch
  • Notes
  • Philips Kathodenstrahl-Oszillograph GM3155;
    Siehe auch das bei Philips Electro Special Berlin (PESB)
    hergestellte Modell Kathograph II GM3155B.
    Frequenzbereich Y- und X-Verstärker: 25...100000 Hz
    Frequenzbereich Kippgerät: 20...20000 Hz
    Synchronisierung der Kippfrequenz mit der Messfrequenz möglich.
  • Net weight (2.2 lb = 1 kg)
  • 7.2 kg / 15 lb 13.7 oz (15.859 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Bernhard Nagel. See "Data change" for further contributors.
