L3X71T /67

L3X71T /67; Philips Belgium (ID = 2330156) Radio L3X71T /67; Philips Belgium (ID = 2329830) Radio
L3X71T /67; Philips Belgium (ID = 2329834) Radio L3X71T /67; Philips Belgium (ID = 2329832) Radio
L3X71T /67; Philips Belgium (ID = 2329833) Radio
Use red slider bar for more.
L3X71T /67; Philips Belgium (ID = 2330156) Radio
Philips Belgium: L3X71T /67 [Radio] ID = 2330156 1400x1037
Select picture or schematic to display from thumbnails on the right and click for download.
For model L3X71T /67, Philips Belgium (Belgien)

Country:  Belgium
Manufacturer / Brand:  Philips Belgium (Belgien)
Year: 1957 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: 2N219 2N218 2N218 OC71 OC71 OC72 OC72 OA79
Main principle Super-Heterodyne (Super in general); ZF/IF 452 kHz; 3 AF stage(s); Export model
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 1 x 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: L3X71T /67 - Philips Belgium Belgien
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 265 x 175 x 85 mm / 10.4 x 6.9 x 3.3 inch
Notes

Philips L3X71T /67 ist eines der ersten ausschliesslich mit Halbleitern bestückten Kofferradios des Herstellers. Dänische Skala (DEN).

Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Mentioned in Funkschau (FS 11/1957, S. 471)

Model page created by Wolfgang Gebert. See "Data change" for further contributors.
