• Year
  • 1959–1961
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 184622

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 452 kHz
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Dry Batteries / 3 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: L3X90T /00X - Philips Belgium Belgien
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 238 x 135 x 60 mm / 9.4 x 5.3 x 2.4 inch
  • Notes
  • Various colours available. The 00X version has a blue case and a white front.
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Jos van den Broek. See "Data change" for further contributors.
