• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1956/1957

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 30279

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 EF89 ECH81 EF85 EF42 EABC80 EL84

• Main principle
• Superhet with RF-stage; ZF/IF 452/10,7 kHz

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Storage and/or dry batteries / 6/12 Volt

• Power out
• 2.5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: N5X61V - Philips; Eindhoven tubes

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 175 x 54 x 155 mm / 6.9 x 2.1 x 6.1 inch

• Notes

• Zerhacker: AP6020

  Preis in der Schweiz SFr 450.

• Net weight (2.2 lb = 1 kg)
• 5.3 kg / 11 lb 10.8 oz (11.674 lb)

• Price in first year of sale
• 5,750.00 BFr

• Author
• Model page created by Iven Müller. See "Data change" for further contributors.
