Olimpia - Olympia U 1791

Olimpia - Olympia U 1791; Philips; Budapest (ID = 2142302) Radio
Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141727) Radio Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141728) Radio
Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141730) Radio Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141732) Radio
Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141733) Radio Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141734) Radio
Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141735) Radio Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141736) Radio
Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141737) Radio Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141738) Radio
Use red slider bar for more.
Olimpia - Olympia U 1791; Philips; Budapest (ID = 2141727) Radio
Philips; Budapest: Olimpia - Olympia U 1791 [Radio] ID = 2141727 1400x1121
Select picture or schematic to display from thumbnails on the right and click for download.
For model Olimpia - Olympia U 1791, Philips; Budapest:
Thanks for the photos, Mr. Sándor Perneky!

Country:  Hungary
Manufacturer / Brand:  Philips; Budapest
Year: 1936–1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: CF7 CL4 CY1 C1 or C2
Main principle TRF with regeneration
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Olimpia - Olympia U 1791 - Philips; Budapest
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 465 x 290 x 200 mm / 18.3 x 11.4 x 7.9 inch
Notes

See also the similar AC version Olympia W 1790.

Price in first year of sale 190.00 Pengő
Literature/Schematics (1) -- Schematic

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
