Oscilloscope GM5666 /02

Oscilloscope GM5666 /02; Philips France; (ID = 1735966) Equipment

Oscilloscope GM5666 /02; Philips France; (ID = 1735967) Equipment

Oscilloscope GM5666 /02; Philips France; (ID = 1735968) Equipment

Oscilloscope GM5666 /02; Philips France; (ID = 1735971) Equipment

Oscilloscope GM5666 /02; Philips France; (ID = 1735972) Equipment

Oscilloscope GM5666 /02; Philips France; (ID = 1735973) Equipment

Oscilloscope GM5666 /02; Philips France; (ID = 1735974) Equipment

Oscilloscope GM5666 /02; Philips France; (ID = 1735975) Equipment

Oscilloscope GM5666 /02; Philips France; (ID = 1735976) Equipment

Oscilloscope GM5666 /02; Philips France; (ID = 1735977) Equipment
Oscilloscope GM5666 /02; Philips France; (ID = 1735719) Equipment
Use red slider bar for more.
Oscilloscope GM5666 /02; Philips France; (ID = 1735719) Equipment
Philips France;: Oscilloscope GM5666 /02 [Equipment] ID = 1735719 933x1069
Select picture or schematic to display from thumbnails on the right and click for download.
For model Oscilloscope GM5666 /02, Philips France; Paris:
photo prise du manuel utilisateur

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1958 ?? Category: Service- or Lab Equipment
Valves / Tubes 26: DL67 DL67 ECC91 EF80 EF80 EF80 ECF80 ECF80 PCF80 PCF80 EY51 ECF80 ECF80 EZ80 GZ34 PL36 85A2 PCF80 PCF80 PCF80 PCF80 EY51 0A2 0B2 DG10-78 EY51 PCF80
Semiconductors (the count is only for transistors) OA86 OA202
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Oscilloscope GM5666 /02 - Philips France; Paris
Material Metal case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 250 x 360 x 530 mm / 9.8 x 14.2 x 20.9 inch
Notes

Oscilloscope à gain élevé, gamme de 0 à 60 kc/s, sensibilité 3mV/cm.

Net weight (2.2 lb = 1 kg) 30 kg / 66 lb 1.3 oz (66.079 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
