Aladyn (Aladin) 102A13

Aladyn 102A13; Philips - Polskie (ID = 1455284) Radio
Aladyn 102A13; Philips - Polskie (ID = 642719) Radio Aladyn 102A13; Philips - Polskie (ID = 642724) Radio
Aladyn 102A13; Philips - Polskie (ID = 642721) Radio Aladyn 102A13; Philips - Polskie (ID = 642723) Radio
Aladyn 102A13; Philips - Polskie (ID = 642727) Radio Aladyn 102A13; Philips - Polskie (ID = 642729) Radio
Aladyn 102A13; Philips - Polskie (ID = 642730) Radio Aladyn 102A13; Philips - Polskie (ID = 642731) Radio
Aladyn 102A13; Philips - Polskie (ID = 257987) Radio Aladyn 102A13; Philips - Polskie (ID = 257988) Radio
Use red slider bar for more.
Aladyn 102A13; Philips - Polskie (ID = 642719) Radio
Philips - Polskie: Aladyn 102A13 [Radio] ID = 642719 671x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Aladyn (Aladin) 102A13, Philips - Polskie Zaklady Philips:
Thanks for Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Poland
Manufacturer / Brand:  Philips - Polskie Zaklady Philips
Year: 1936/1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: AF7 AL4 AZ1
Main principle TRF with regeneration; 1 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker -Loudspeaker incorporated, but system not known.
Power out
from Radiomuseum.org Model: Aladyn 102A13 - Philips - Polskie Zaklady
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 405 x 375 x 215 mm / 15.9 x 14.8 x 8.5 inch
External source of data Erb
Source of data -- Original-techn. papers.


All listed radios etc. from Philips - Polskie Zaklady Philips
Here you find 46 models, 31 with images and 21 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
