RK35 EL3531D /22a

• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1960

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 87300

• • Brand: Deutsche Philips-Ges.

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• EF86 EF86 ECC83 ECC83 EM84 ECC81 EL95

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 2.5 W (unknown quality)

• Material
• Various materials

• from Radiomuseum.org
• Model: RK35 EL3531D /22a - Philips Radios - Deutschland

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 375 x 175 x 315 mm / 14.8 x 6.9 x 12.4 inch

• Notes
• RT35 in anderem Gehäuse. 4-Spur Tonbandgerät.

• Net weight (2.2 lb = 1 kg)
• 9.2 kg / 20 lb 4.2 oz (20.264 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.
