Rubin SF19T630

Rubin SF19T630; Philips Finland - (ID = 1292390) Television

Rubin SF19T630; Philips Finland - (ID = 1292391) Television

Rubin SF19T630; Philips Finland - (ID = 1292392) Television

Rubin SF19T630; Philips Finland - (ID = 1292393) Television

Rubin SF19T630; Philips Finland - (ID = 1292388) Television

Rubin SF19T630; Philips Finland - (ID = 1292389) Television
Rubin SF19T630; Philips Finland - (ID = 1292296) Television
Use red slider bar for more.
Rubin SF19T630; Philips Finland - (ID = 1292296) Television
Philips Finland -: Rubin SF19T630 [Television] ID = 1292296 600x857
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rubin SF19T630, Philips Finland - see also Fenno and TeRate:
Radiokauppias 5/1966

Country:  Finland
Manufacturer / Brand:  Philips Finland - see also Fenno and TeRate
Year: 1966/1967 Category: Television Receiver (TV) or Monitor
Valves / Tubes 14: PCF801 PC900 PCF201 PCF200 PCL84 PCF200 PCF802 PCL85 PCL86 PL84 PL500 PY81 DY87 A47-11W
Semiconductors (the count is only for transistors) 3:
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Rubin SF19T630 - Philips Finland - see also
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes 19 inch B/W television, UHF optional.
Price in first year of sale 760.00 FIM
Source of data -- Schematic

Model page created by Jouko Laukkanen. See "Data change" for further contributors.
