Savoy Automatic Console A23T676 /02 Ch= F4-KÄ (F4-N)

Savoy Automatic Console A23T676 /02 Ch= F4-KÄ ; Philips - Österreich (ID = 292271) Television

Savoy Automatic Console A23T676 /02 Ch= F4-KÄ ; Philips - Österreich (ID = 292272) Television

Savoy Automatic Console A23T676 /02 Ch= F4-KÄ ; Philips - Österreich (ID = 1952163) Television
Savoy Automatic Console A23T676 /02 Ch= F4-KÄ ; Philips - Österreich (ID = 153954) Television Savoy Automatic Console A23T676 /02 Ch= F4-KÄ ; Philips - Österreich (ID = 153995) Television
Use red slider bar for more.
Savoy Automatic Console A23T676 /02 Ch= F4-KÄ ; Philips - Österreich (ID = 153954) Television
Philips - Österreich: Savoy Automatic Console A23T676 /02 Ch= F4-KÄ [Television] ID = 153954 614x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Savoy Automatic Console A23T676 /02 Ch= F4-KÄ (F4-N), Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1968 Category: Television Receiver (TV) or Monitor
Valves / Tubes 12: EF183 PCF200 PCL84 PCL86 PL84 PCH200 PCF802 PCL805 PL504 PY88 DY802 A59-11W
Semiconductors (the count is only for transistors) 8: AF239 AF239 AF139 BF173 AF126 BF115 AC125 AC132
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Savoy Automatic Console A23T676 /02 Ch= F4-KÄ - Philips - Österreich
Material Wooden case
Shape Console, Highboy (legs > 50 %).
Dimensions (WHD) 760 x 490 x 430 mm / 29.9 x 19.3 x 16.9 inch
Notes

Fernsehband VHF (I+III), UHF (IV/V). 59-cm-Rechteckbildröhre.
Ohne den eingeschraubten Beinen auch als Tischgerät verwendbar.

Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
