Super-Inductance 834S

Super-Inductance 834S; Philips France; (ID = 2003987) Radio Super-Inductance 834S; Philips France; (ID = 2003988) Radio
Super-Inductance 834S; Philips France; (ID = 2003989) Radio
Use red slider bar for more.
Super-Inductance 834S; Philips France; (ID = 2003987) Radio
Philips France;: Super-Inductance 834S [Radio] ID = 2003987 800x572
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super-Inductance 834S, Philips France; Paris:
L'Est Républicain, 09.09.1933

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1933/1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: TE55 TE52 TE99 TC43 TV80 or V80
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Super-Inductance 834S - Philips France; Paris
Material Special material, described in the notes.
Shape Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
Notes

Régulateur pour l'élimination de l'émetteur local.

Coffret en arbolite.

Équivalent au Radiola 428A.

Price in first year of sale 1'850.00 FRF
Mentioned in -- Original prospect or advert (L'Est Républicain, 09.09.1933)
Literature/Schematics (1) Radio Constructeur et Dépanneur (Correspondance Philips - Radiola, Juillet-Août 1956)

Model page created by Mark Hippenstiel. See "Data change" for further contributors.



All listed radios etc. from Philips France; Paris
Here you find 545 models, 482 with images and 297 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
