For model Videomat 19 19TA441A /00 /01 /08 Ch= P6, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1964 Category: Television Receiver (TV) or Monitor
Valves / Tubes 20: PC88 PC86 PCC189 PCF86 EF183 PCF200 PCF200 PCL84 PCL85 PCL86 ECH84 PCF80 PF86 PCL85 ECH84 PCF802 PL500 PY88 DY87 A47-11W
Semiconductors (the count is only for transistors) 3: AF126 AF126 AF126
Main principle Superhet with RF-stage
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 190-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Videomat 19 19TA441A /00 /01 /08 Ch= P6 - Philips - Österreich
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 515 x 395 x 340 mm / 20.3 x 15.6 x 13.4 inch
Notes

Fernsehband VHF (I+III), UHF (IV/V).
3 Ausführungen:
/00 Kassette dunkel-hochglänzend, UHF-Röhrentuner;
/01 Kassette dunkel-hochglänzend, UHF-Transistortuner mit 2×AF186 statt PC88 und PC86;
/08 Kassette dunkel-hochglänzend, ohne UHF.

Paralleltype zum Horny W48T144A.

Neupreise:
ohne UHF: ATS 5280,--
mit UHF: ATS 5780,--

Net weight (2.2 lb = 1 kg) 20 kg / 44 lb 0.8 oz (44.053 lb)
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
