5501

5501; Phonola SA, FIMI; (ID = 258407) Radio

5501; Phonola SA, FIMI; (ID = 258408) Radio

5501; Phonola SA, FIMI; (ID = 258409) Radio
5501; Phonola SA, FIMI; (ID = 866378) Radio 5501; Phonola SA, FIMI; (ID = 520763) Radio
5501; Phonola SA, FIMI; (ID = 520764) Radio 5501; Phonola SA, FIMI; (ID = 520762) Radio
5501; Phonola SA, FIMI; (ID = 866379) Radio 5501; Phonola SA, FIMI; (ID = 866380) Radio
5501; Phonola SA, FIMI; (ID = 866382) Radio 5501; Phonola SA, FIMI; (ID = 866386) Radio
5501; Phonola SA, FIMI; (ID = 1347362) Radio 5501; Phonola SA, FIMI; (ID = 1347363) Radio
Use red slider bar for more.
5501; Phonola SA, FIMI; (ID = 866378) Radio
Phonola SA, FIMI;: 5501 [Radio] ID = 866378 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model 5501, Phonola SA, FIMI; Saronno (VA):

Country:  Italy
Manufacturer / Brand:  Phonola SA, FIMI; Saronno (VA)
Year: 1948 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH4 EF9 EBC3 EL3 AZ1
Main principle Superheterodyne (common); ZF/IF 470 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 120; 140; 160; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 5501 - Phonola SA, FIMI; Saronno VA
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 600 x 240 x 210 mm / 23.6 x 9.4 x 8.3 inch
Notes

Gamme d'onda: 2 medie, corte, cortissime.
Wave bands: 2× BC, 2× SW.

Ingresso per giradischi.

Literature/Schematics (1) Schemi di apparecchi radio ( Ravalico 1953 ) (pag. 240-241)

Model page created by Alessandro De Poi. See "Data change" for further contributors.
