• Year
  • 1970/1971
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 206919

 Technical Specifications

  • Number of Transistors
  • 7
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / 3 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
  • Power out
  • 0.2 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Señor RT7185 - Phonola SA, FIMI; Saronno VA
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 103 x 103 x 41 mm / 4.1 x 4.1 x 1.6 inch
  • Net weight (2.2 lb = 1 kg)
  • 0.310 kg / 0 lb 10.9 oz (0.683 lb)
  • Author
  • Model page created by Alessandro De Poi. See "Data change" for further contributors.
