C-245 ; Pilot Electric Mfg. (ID = 598440) Radio

C-245 ; Pilot Electric Mfg. (ID = 598441) Radio

C-245 ; Pilot Electric Mfg. (ID = 598442) Radio
Use red slider bar for more.
C-245 ; Pilot Electric Mfg. (ID = 598440) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
alternative name

Pilot Radio & Television || Pilot Radio and Tube || Pilot Radio Corporation
Year: 1936 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6K7 6A8 6K7 6H6 6J7 6F6 5Z4
Main principle Superhet with RF-stage; ZF/IF 456 kHz
Tuned circuits 9 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 115; 125; 150; 220; 240 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: C-245 - Pilot Electric Mfg. Co. Radio
Notes Export model.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 7 = 1936 and before
