Curtain of Sound 240; Pilot Electric Mfg. (ID = 528774) Ampl/Mixer
Pilot Electric Mfg.: Curtain of Sound 240 [Ampl/Mixer] ID = 528774 720x280
Select picture or schematic to display from thumbnails on the right and click for download.
For model Curtain of Sound 240, Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY):
aus ebay, Verkäufer benny1benny

Country:  United States of America (USA)
Manufacturer / Brand:  Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
alternative name

Pilot Radio & Television || Pilot Radio and Tube || Pilot Radio Corporation
Year: 1959 ? Category: Audio Amplifier or -mixer
Valves / Tubes 10: 12AX7 12AX7 12AX7 12AX7 12AX7 EL84 EL84 EL84 EL84 GZ34
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 105 - 120 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Curtain of Sound 240 - Pilot Electric Mfg. Co. Radio
Material Metal case
Shape Book-shelf unit.
Notes Stereophonic Preamplifier-Amplifier; with Simpli-Matic test panel.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 478 folder 14 date 3-60)

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
