- Country
- United States of America (USA)
- Manufacturer / Brand
- Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
- Year
- 1959
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 153363
-
- alternative name: Pilot Radio & Television || Pilot Radio and Tube || Pilot Radio Corporation
Sams Photofact Folders
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 105 - 120 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 60 W (120 W max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: SA-260 - Pilot Electric Mfg. Co. Radio
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 15 x 5 x 7 inch / 381 x 127 x 178 mm
- Notes
- The Pilot Model SA-260 is an AC Operated 9 Tube Stereo Amplifier.
- Net weight (2.2 lb = 1 kg)
- 30 lb 0 oz (30 lb) / 13.620 kg
- Price in first year of sale
- 119.50 $
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 1-60, Set 469, Folder 14)
- Literature/Schematics (2)
- Radio Shack Catalog (1959, page 9)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
