• Country
• France

• Manufacturer / Brand
• Power-Tone; Paris

• Year
• 1936 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 258099

• Number of Tubes
• 5

• Valves / Tubes
• AK2 AF3 ABC1 AL2 AZ1

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Details
• Visual Tuning Indicator pre Eye

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Super Octode S.O. 400 [lampes série A] - Power-Tone; Paris

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 410 x 450 x 250 mm / 16.1 x 17.7 x 9.8 inch

• Notes

• Ce récepteur existe également avec lampes européennes série E.

  indicateur à ombre

• Net weight (2.2 lb = 1 kg)
• 11.5 kg / 25 lb 5.3 oz (25.33 lb)

• Literature/Schematics (1)
• Le grand livre de la TSF (Doctsf Ref 26418, lampes série E)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
