- Country
- Great Britain (UK)
- Manufacturer / Brand
- Pye Ltd., Radio Works; Cambridge
- Year
- 1953
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 97439
An older advert
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 15
- Valves / Tubes
- EF80 EF80 EF80 EF80 EF80 ECC81 EB91 PL81 EY51 PY81 EF80 ECL80 ECL80 PY82 MW31-16 or MW31-74
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- AC/DC-set / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: V2 - Pye Ltd., Radio Works;
- Shape
- Tablemodel, low profile (big size).
- Notes
- 12" TV with one channel VHF Band 1 Tuner.
- Source of data
- -- Collector info (Sammler)
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1132/T52)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
